1. Monitoring function: It can monitor total current, voltage, power, energy consumption, power factor, current of each socket, and on/off control of each socket
Temperature/humidity, smoke sensing, water immersion, access control, etc., LCD with button display screen.
2. Control function: On/Off control, setting the on/off time for each socket, and setting the startup delay
3. Local Save: Save the original state of each output unit upon restart
4. Custom alarm: Alarm when the total current/load current, temperature and humidity exceed the threshold.
5. System default alarm: occurs when the total load current and various outputs exceed the rated value, smoke sensing, water ingress, access control, etc.
6. Multiple alarm methods: buzzer alarm, website red font reflecting abnormality, LCD screen popping up abnormal information page, automatic reporting to the tube
The manager sends an email, SNMP sends Trap alarm status information, and the indicator light is working abnormally, flashing green and orange.
7. Cascading function: Supports hardware cascading, including up to 4 hosts
8. User management: User permission management. (5 users, including administrators, can be assigned different permissions for each user, divided into input)
Unit, sensor, network, device, user, log management)
9. Access methods: WEB, SNMP (V1/V2c/V3), Telnet/SSH, Modbus RTU
10. Support multi-user operating systems and software upgrades
11. Support hot swapping
12. This product is compatible with third-party Modbus/SNMP/HTTP protocol systems
