Main advantages:
1. The maximum load per phase is 160A, 240V/415V 160Amp 115KW.
2. Multiple brand circuit breaker options.
3. Supports multifunctional selection of PDU sockets. For example, the color of the socket can be red, yellow, and blue, all black, or a black socket with IEC locking function, which is tighter and safer.
4. Support customization of house colors, such as red, yellow, blue, white, purple, black, etc
5. Humanized design, adding 3 C13 small output ports to provide power for network switches.
6. Each socket has an independent circuit and circuit breaker. In addition, the main input terminal box is equipped with a 180A fuse for input protection, providing detailed dual protection.
7. Customized installation bracket with multiple positioning screw holes to make the PDU lock more secure. The socket standard includes 24 C19 sockets (can be changed according to customer requirements) with input voltage ranging from 240V single-phase (LNG) to 240V single-phase and 380V three-phase (LLLNG) to 220V single-phase. 415V three-phase (LLLNG) to 240V single-phase, 480V three-phase (LL liquefied natural gas) to 277V single-phase. Input connector 160A x 5-wire (or junction box)
8. The input circuit breaker is optional, with a frequency of 50/60Hz and a maximum total current of 480A depending on the price,
9. Flame retardant function remote control integration remote control each socket, TCP/IP, hot swappable control instrument color black or customized shell material non flammable PC module, metal plate shell installation method horizontal or vertical installation net weight 20kg
10. Support OEM/ODM
